IMJB series slurry magnetic pump (slurry magnetic pump for short) is a magnetic drive pump negative pressure conveyor belt particle slurry technology , which occupies the forefront of domestic science and technology and has achieved the first historic breakthrough, making it possible for magnetic drive pump negative pressure operation and conveyor belt particle slurry.

The pump has adopted the latest technology in the same industry at home and abroad, and has been successfully tested!

At present, all magnetic pumps at home and abroad can not transport material paddles and solid particles.

The reason is that the slurry into the isolation sleeve is easy to block, the inner magnetic can not drive, and the outer magnetic isolation sleeve produces high temperature.

The inner and outer magnetic fields are easy to demagnetize, and the sliding bearing is easy to wear.

Within the original magnetic and isolation system with sliding bearing, because the magnetic fluid, and isolation is the positive pressure, the liquid flow is slow, so easy to jam and generate heat, IMJB series slurry magnetic pump research and development success every changed the traditional magnetic pump for conveyor belt particle size run with magnetic eddy current heat burn out of the pump slide pomelo vice and magnetic bearing, caused the inner rotor and isolation sets of scratches,

Damage to the pump, medium leakage, such as chain reaction with surrounding facilities and the environment, will likely cause greater losses and even lead to safety accidents.

IMJB series slurry magnetic pump is a new product which applies the working principle of permanent magnet coupling shaft to centrifugal pump. It has the characteristics of full sealing, no leakage and corrosion resistance with reasonable design and excellent technology.

The magnetic pump is composed of three parts: pump, magnetic drive and motor.

The key component of the magnetic drive is composed of an external magnetic rotor, an internal magnetic rotor and a non-magnetic isolation sleeve.

When the motor drives the external magnetic rotor to rotate, the magnetic field can penetrate the air gap and non-magnetic material, driving the internal magnetic rotor connected with the impeller to rotate synchronously, realizing the non-contact transmission of power, and transforming the dynamic seal into a static seal.

Because the pump shaft, the internal magnetic rotor is completely closed by the pump body and the isolation sleeve, it completely solves the problem of "running, running, dropping and leakage", and eliminates the safety hidden danger of flammable, explosive, toxic and harmful media in the oil refining and chemical industry through the seal and leakage of the pump.

The main features

IMJB series slurry magnetic force pump has the following important characteristics: its structure adopts radial inlet, axial outlet, suction inlet in the side of the magnetic and isolation sleeve is negative pressure, isolation sleeve without blockage, isolation sleeve outside the surface and inside the magnetic outside composite wear-resistant and corrosion resistant materials.

IMJB series slurry parts of magnetic pump are made of full stainless steel material, the organic acid, organic compound, alkali, neutral solution and a kind of gas has good corrosion resistance, double helix carbon graphite bearing and grinding of cemented carbide shaft sleeve, strong wear resistance, ensure the service life of products, is no leak forhandling corrosive, particle slurry medium ideal choice.

Scope and purpose of use

IMJB stainless steel magnetic slurry pump can transport containing fine suspended particles, temperature below 250℃ of any acid and alkali organic content, etc., is chemical, petroleum, chemical fiber, pharmaceutical, highly toxic, flammable, explosive and other valuable liquid processing industry of the first products.
